Pintech CP-3101R (100MHz,600V) Oscilloscope Probe

Pintech CP-3101R



Product Introduction
Product Name : CP-3101R (100MHz,600V) Oscilloscope Probe Short Description : Max.Working Voltage : 600V dc;1000V peak;300V rms Have Cursor Readout Bandwidth : 100MHz

Pintech CP-3101R Specification

Division Ratio 10:1
Band width DC~100MHz
Rise Time 3.5nS
Input Resistance 10 MΩ
Input Capacitor About 16PF
Compensation Range 10~35PF
Operating Voltage 600V DC+AC peak
DC Accuracy ≦1%
Temp.Coefficient ≦200ppm/℃
Cable Length 1.2M
Operating Temp. 0℃~+50℃ or less 85%RH（35℃）
Storage Temp. -20℃~+70℃ or less 90%RH
weight 90g
