| Model | PA6610 |
| Output DC current rating(0?~40?) |
| Voltage | 0~60V |
| Current | 0~10A |
| Over-voltage protection | 0.1~64V |
| Over-current protection | 0.1~12A |
| Output voltage |
| Power effect | =0.01%+4mV |
| Load effect | =0.1%+5mV |
| Recovery time | =1.5ms (50% load change) |
| Ripple and noise | 2mVrms, 30mVpp |
| Temperature coefficient | =300ppm/? |
| Setting accuracy | ±(0.03% of reading + 10mV) (25±5?) |
| Setting resolution | 1mV |
| Output current |
| Power effect | =0.2%+3mA |
| Load effect | =0.2%+5mA |
| Ripple and noise | =10mArms |
| Setting accuracy | ±(0.3% of reading + 10mA) (25±5?) |
| Setting resolution | 1mA |
| Display |
| Voltage | 5 digits display |
| Current | 5 digits display |
| Voltage resolution | 1mV |
| Current resolution | 1mA |
| Reading accuracy | ±(0.02% of reading +5mV) (25±5?);±(0.05% of reading +10mA) (25±5?) |
| Protection | Overload protection, polarity reverse protection, over-voltage protection, over-current protection, over temperature protection |
| Long-distance sensing | Maximum compensing voltage0.1V |
| Battery charging | Lithium battery curve Charging |
| Connector | Standard RS232connectir,Support SCPI instruction set, analog control interface(optional) |
| Store/Pull memory | 100group |
| Insulating degree | Between the output terminal and the casing or other terminals:=60VDC |
| Operation | indoor | Altitude:=2000m | Environment temperature:0~40? |
| | Humidity:=80% | Installation level:II | Pollution level:2 |
| Storage | Environment temperature:-10~70? Humidity:=70% |
| Power input | AC 220V±10%, 50/60Hz |
| Accessories | Instruction manualx1,power cablex1,RS232connector cablex1 |
| Size | 412(D)×215(W)×89(H)mm |
| Weight | 4.5kg |
