Pintech PT710-F (500KHz,300Ap-p) AC/DC current probe clamp

Pintech PT710-F



Bandwidth : 500KHz Max. DC : 150A Max. AC : 300Ap-p,140Arms 2 Ranges : 5mV/A; 50mV Battery and adaptor power supply Including MT-246N (BNC to banana interface) ,use for DMM measuring.

Pintech PT710-F Specification

Model PT710-F
Feature DC-300KHz,=10mA,low noise
Max. DC AC Current 150A DC
Max.AC Peak to Peak 300A P-P
Max. AC RMS 106A RMS
Range Selection Division 2 Range 5mV/A;50mV
Max. Test Wire Dia. =11F
Max. Sensitivity 5mA
Bandwidth(-3dB) DC~500KHz
Rise time 0.7s
DC Accuracy(Typical) 3%:30mA~15A at 50mV/A4%:300mA~80A at 5mV/A15%:20A~150A
Size & weight 280mm (L) x 70mm (D) x 32 mm (H)260g
Max. Working voltageMax. Floating voltage 300V CAT III600V CAT II
Power supply Battery(9V NEDA 1604A)or adaptor(included)
Accessories BP-250, MT-246N, Adaptor,
