Pintech PT-5216 (100MHz,16KVp-p) differential probe

Pintech PT-5216



Overload protection differential probe PT-5216 Max. Measuring voltage : 8KV DC or 16KV p-p or AC 5.6KVrms Bandwidth : DC-100MHz Input impedance : 30MO// 1.5PF Attenuation ratio : x20, x200, x2000 Max. Ground voltage : 8KV CAT III Input impedance : 50O

Pintech PT-5216 Specification

Model PT-5216
Bandwidth(50O load-3Db) 100MHz
Input differential voltage(DC+AC peak to peak) 16KV
Input differential voltage AC/RMS 5650V
Attenuation ratio(Switchable) 20, 200. 2000
Input impedance(Between Input) 30MO//1.5PF
Noise (Into 50O Load) =2mV rms
Accuracy =2%
Max. Output =4V
Input impedance 50O
Power supply 9V/35mA
Dimension 220x85x30mm
