Pintech PT-2740 (300KHz,2A-500A) current probe

Pintech PT-2740



PT-2740 (300KHz,2A-500A) current probe Bandwidth : 300KHz Accuracy : 2% Attenuation ratio : 20mV/A,2mV/A Current range : 250A DC,500Ap-p AC

Pintech PT-2740 Specification

Model Number PT-2740
Range 20mV/A 2mV/A
Current range DC: 2A~30AAC:2A~60Ap-p DC:30A~250AAC:60A~500Ap-p
Output signal error 2% 2%
Bandwidth(-3dB) DC~150kHz
Load impedance =1MO and =100pF
Impedance 0.01O
Noise 2mVp-p
Rise time 1.2Ás
Operating voltage Max.600Vrms
CMRR Max.600Vrms
Battery 9V
Low battery indicator with green LED light when >6.5V
Overload indicator Red LED light indicates the over measuring current, change the range
Mechanical Specifications
Operating temperature 0~+50?
Storage temperature -3~+80?
Temperature influence Every 10?,<0.2%
Operating relative humidity +10?~+30?:85▒5% relative humidity(non-condensing )+40?~+50?:45▒5%relative humidity(non-condensing )
Operating height 0~2000m
Max clam size Diameter 10.3mm
Dimension 231?36?67mm
Weight 310g(not including battery)
Output 2 meters of coaxial cable, with insulation BNC connector jack at the end
