Pintech DP-7500 (50MHZ,7000Vp-p) differential probe

Pintech DP-7500



Bandwidth : 50Mhz Max. measuring voltage : 7000Vp-p Attenuation ratio : X100 X200 X500 X1000 Accuracy : 2%

Pintech DP-7500 Specification

Model DP-7500
Bandwidth(50O overload) DC-50MHz(X100 gear 25MHz)
Accuracy 2%(heat the machine after twenty minutes)
Division Ratio Rotary switch X100,X200,X500,X1000
Max. operating voltage (DC/AC peak to peak) When X100, =350V DC,700Vp-p AC When X200, =700V DC,1400Vp-p ACWhen X500, =1250V DC,3500Vp-p AC When X1000, =3500V DC,7000Vp-p AC
Differential Range 7000V(DC+AC peak to peak)
CMRR 60Hz:>10000:1
100Hz:>1000:1
1MHz:>300:1
Noise =2mVrms
Power 9VPower Adapters(AC Adaptor)
Consumption 9V/35mA
Size 235mm(L)X85mm(W)X35mm(H)
Weight 290g
Fitting BP-250,BP-256N,BP-276,BP-366,ADP-220
