Pintech DP-50 (50MHZ, 7000Vp-p) differential probe

Pintech DP-50



Bandwidth : 50MHz Max. measuring voltage : 7000 (Vp-p) Attenuation ratio : X100 X200 X500 X1000 Accuracy : 2%

Pintech DP-50 Specification

Model DP-50
Bandwidth(50O overload) DC-50MHz(X100 range 25MHz)
Accuracy 2%(heat the machine after twenty minutes)
Division Ratio X100,X200,X500,X1000
Max. operation voltage(DC,AC peak to peak) When X100,350V DC , 700Vp-p ACWhen X200, 700V DC,1400Vp-p ACWhen X500, 1700V DC,3400Vp-p AC When X1000,3500V DC,7000Vp-p AC
Differential Range 7000V(DC+AC peak to peak)
Absolute max. voltage(CMRR) 60Hz:>10000:1
100Hz:>1000:1
1MHz:>300:1
Noise =2mVrms
Input Resistance 54MO//1.2PF
Max. Consumption 9V/35mA
Size 235mm(L)X85mm(W)X35mm(H)
Weight 290g
Fitting BP-250,BP-256N,BP-276,BP-366,ADP-220
