Advantest TR4133B Spectrum Analyzer (ADV TR4133B)

The Advantest TR4133 / TR4133A / TR4133B spectrum analyzers are microprocessor – based intelligent spectrum analyzers covering a broad frequency band from 100 kHz to 20 GHz. With an external mixer (accessory) the TR4133/4133B provide further expansion in the measuring frequency range. The TR4133 has no external mixer. The TR4133/4133B use to first-stage mixer: a 100 KHz to 3.6 GHz balancing mixer and a 10 MHz to 20 GHz (3.5 GHz to 20.0 GHz for the TR4133B) harmonics mixer. The low-loss balancing mixer, featuring a low average noise level of -118 dBm (with a resolution bandwidth of 1 KHz), permits precise measurement.

Advantest TR4133B with Advantest TR4133 / A / B Manual (Vol. 1 & 2)


Advantest TR4133B Spectrum Analyzer (ADV TR4133B) Advantest TR4133/A/B Spectrum Analyzer Manual


2 IN STOCK

Condition : Just Like New


Advantest TR4133B Price


Advantet TR4133/A/B Datasheet

The harmonics mixer enables frequencies up to 20 GHz to be measured by mixing the fundamental wave from the first local oscillator with harmonic waves. The higher the order of such mixing, the greater the conversion loss, impairing sensitivity. A 4 GHz to 8 GHz tuned oscillator used as the first local oscillator in the TR4133/A/B provides lower-order mixing, assuring precise measurement of frequencies up to 20 GHz.

Advantest TR4133B I/O



Advantest TR4133B Front Panel



Get your
Advantest TR4133B quotation today.





Advantest TR4133B Quotation




Related Links
Advantest  |  Spectrum & Network Analyzers



(All trademarks acknowledged) E. & O. E.

The Advantest TR4133 / TR4133A / TR4133B spectrum analyzers have a built-in counter for frequency measurement. A marker function permits reading frequencies and levels in digital form.

The TR4133A / TR4133B with a built-in preselector provides a 100 dB dynamic range in harmonics measurement (frequency band 3.5 GHz to 20 GHz.) All switches can be remote controlled by GPIB interface supplied as standard. The current setting of the spectrum analyzer’s functions are displayed on the CRT screen. A hard copy of display image can be produced by connecting the VIDEO OUT terminal on the back panel to a video plotter.

The TR4133 / TR4133A / TR4133B spectrum analyzers feature an easy to operate key layout, in which three primary controls (center frequency, frequency span, and reference level) are centralized in the panel. These controls automatically set the IF bandwidth, sweep time, and input attenuator to optimum levels, simplifying the process of setting frequency observation conditions.

Advantest TR4133B Features

  • Microprocessor-based intelligent spectrum analyzer covering a broad frequency band from 100 KHz to 21 GHz
  • Frequency Band 3.5GHz to 21 GHz
  • Built in preselector provides a 100 dB Dynamic Range in Harmonic Measurement
  • Built in Counter for frequency Measurements
  • Marker function
  • GPIB interface for remote controlling

Ask for Advantest TR4133B detailed specification.
